HEOS Drive 4 Zone Amplifier Multiroom System

Finally a multi-room distributed streaming audio product packed with features designed with integration in mind. With similar functionality as both the HEOS Amp and HEOS Link the HEOS Drive delivers four powerful streaming zones using eight-channels of class-D amplification within a single 2RU, 19” rack mountable chassis.

eisaaward

$3,999.00

As a part of our dealer agreement this product is unavailable for online sale.
  Please CONTACT US or Call Now for purchasing options.

Finally a multi-room distributed streaming audio product packed with features designed with integration in mind. With similar functionality as both the HEOS Amp and HEOS Link the HEOS Drive delivers four powerful streaming zones using eight-channels of class-D amplification within a single 2RU, 19” rack mountable chassis. This features the ability to play cloud music from Spotify®, Deezer ™, Pandora®, TuneIn with TIDAL on the way as well as many others. Also play music stored locally on your smartphone, tablet, PC, Mac, USB or USB and NAS drive too all in a single tidy, space saving design!

Features
  • Four HEOS Zones
  • Eight Channel Class-D Amplifier
  • 70 Watts per channel (0.05% THD)
  • Dedicated preamplifier output for each zone (selectable as stereo zone or subwoofer)
  • Two Fibre Optic, Two Digital Coax and Four Analog Inputs (Matrix switching)
  • Dolby Digital Decoding
  • Third Party Control Compatible - RTI, Crestron, Roomie Remote, Compass Control available now.  URC, Control 4, Elan/Niles &  ProControl arriving soon.
  • IP Control of Denon and Marantz AVRs – power, input changing and two way volume from inside the HEOS app.
  • Four USB Inputs – streaming to any HEOS zone
  • Amplifier Bridge Capability (boost output power to any zone and line out the 2nd zone to another amp/receiver)
  • 4 Ohms Drive Certification
  • Selectable Stereo / Mixed Mono Output
  • Selectable High Pass / Low Pass Filters
  • 4 x 12V Trigger Outputs - perfect for commercial power amps etc.
  • Input Renaming Capability
  • Four-Way Binding Posts
  • Two Ethernet Inputs
  • Actively Cooled
  • 2RU Rack Height (with feet removed) - Rack Ears Included
Specification
Audio System
Power Amplifier Rated output
  • 8x 60W (20Hz-20kHz, 0.5% THD, 8 Ohms)
Impedance
  • 4 Ohms Compatible

Total Distortion
  • 0.05% THD

Frequency response
  • 20Hz-20kHz

Outputs
  • 8x Speaker Outputs (2ch per zone)
  • 4x Stereo RCA Pre-Out
  • 4x 3.5mm 12v Trigger
Bridging Options
  • Z1+Z2 Amplifiers (Z1 Control)
  • Z3+Z4 Amplifiers (Z3 Control)
  • Z2 and Z4 Pre-Outs function as normal when amplifiers are in bridge mode.
Music Sources
Streaming Services
  • TIDAL Connect
  • Spotify Connect
  • Deezer
  • Amazon Music HD
  • iHeartRADIO
  • SoundCloud
  • Internet Radio provided by TuneIn
Inputs
  • 4x RCA Line In (L&R Per Zone)
  • 4x USB-A (Mass Storage, Per Zone)
  • 2x Optical Digital
  • 2x Coaxial Digital
Music Formats Supported
  • WMA (Up to 192kbps)
  • AAC (320kbps)
  • MP3 (320kbps)
  • WAV (24bit/192kHz)
  • ALAC (24bit/192kHz)
  • FLAC (24bit/192kHz)
Networking
Ethernet
  • Dual RJ45 LAN
General
Power Supply
  • AC 220-240V
  • 50/60Hz
Controls & Indicators
  • Power/Standby Button
  • Ethernet Status 1/2
  • Zones 1-4 Active Status
Dimensions
  • 430mm Width
    • 483mm Width with Rack Ears
  • 402mm Depth
  • 88mm Height (2RU)
Weight
  • 7.2kg
Package Contents
  • HEOS Drive HS2
  • AC Power Cable
  • RJ45 Ethernet Cable
  • Quick Start Guide
  • 2 Rack Ears
Operating Temperature Range
  • 5°C~35°C

Product Finish
  • Black
